7050-01-369-2786 (7050013692786) NSN Information
| Photo | NSN | FSC | NIIN | Item Name | INC |
|---|---|---|---|---|---|
 | 7050-01-369-2786 | 7050 | 013692786 | Converter, Analog to Digital | 62117 |
7050-01-369-2786 Features
| MRC | Parameter | Characteristics |
|---|---|---|
| ABHP | Overall Length | 2.120 inches nominal |
| ABKW | Overall Height | 1.100 inches nominal |
| ABMK | Overall Width | 2.030 inches nominal |
| AFGA | Operating Temp Range | -0.0/+70.0 deg celsius |
| CPLR | Unit Design | Panel mounted |
| CSBH | Voltage in Volts and Current Type | 24.0 dc |
7050-01-369-2786 Manufacturing Part Numbers (SKUs)
| MFG SKU | CAGE | STATUS | ISC | RNVC | RNCC | SADC | DAC | HCC | RNAAC |
|---|---|---|---|---|---|---|---|---|---|
| G4AD7 | 55442 | A | 2 | 5 | TX | ||||
| PL37245122 ITEM 37 | 01534 | A | 2 | 3 | TX |
7050-01-369-2786 Manufacturer
| MFG SKU | CAGE | Manufacturer | Type | Status | Role |
|---|---|---|---|---|---|
| G4AD7 | 55442 | Opto 22 | A | A | |
| PL37245122 ITEM 37 | 01534 | Raytheon Company | A | A |
7050-01-369-2786 FLIS Identification
| PMIC | ADPE CODE | CRITL CODE | DEMIL CODE | DEMIL INTG | NIIN ASGMT | ESD | HMIC | ENAC | SCHEDULE_B | INC |
|---|---|---|---|---|---|---|---|---|---|---|
| A | 0 | X | A | 1 | 18-DEC-1992 | N | 8473500000 | 62117 |
7050-01-369-2786 FLIS Management
| MOE | REC REP CODE | MGMT CTL | USC | PHRASE CODE | PHRASE STATEMENT |
|---|---|---|---|---|---|
| DN | 9B----- | N | |||
| DS | ------- | I |
7050-01-369-2786 Demilitarization Codes & Management
| DML | PMIC | HMIC | ADPEC | Criticality | ESDC |
|---|---|---|---|---|---|
| A | N | 0 | X |
7050-01-369-2786 Miscellaneous Management
| MOE (S_A) | SOS | AAC | QUP | UI | SLC | CIIC | RC | MCC | SVC |
|---|---|---|---|---|---|---|---|---|---|
| DN | SMS | J | 1 | EA | 0 | U | 9B----- | I | |
| DN | SMS | J | 1 | EA | 0 | U | 9B----- | N | |
| DS | SMS | J | 1 | EA | 0 | U | ------- | I | |
| DS | SMS | J | 1 | EA | 0 | U | ------- | N |
7050-01-369-2786 Component / End Item
| WPN SYS ID | WPN SYS SVC | WEAPON SYSTEM |
|---|---|---|
| MT | N | Waters Class TAGS-45 |
7050-01-369-2786 Non-consumable Item Support
| MOE RULE | NIMSC | DSOR |
|---|---|---|
| N9BZ | ||
| BGX1 |
7050-01-369-2786 Management Control Navy
| COG | SMIC | IRRC | SMCC |
|---|---|---|---|
| 9B |
7050-01-369-2786 Freight
| NMFC | NMFC SUB | UFC | HMC | LTL | LCL | WCC | TCC | SHC | ADC | ACC | ASH | NMF DESC |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 116030 | Z | 59295 | W | 734 | Z | 9 | A | SZ |
7050-01-369-2786 FLIS Packaging 1
| PICA SICA | TOS | ICQ | MOP | CLNG DRYING | PRES MAT | WRAP MAT | PKG CAT | PKG DESIGN ACTY | CUSH DUN |
|---|---|---|---|---|---|---|---|---|---|
| P | AAA | 42 | 1 | 00 | 00 | 69F0 | NA |
7050-01-369-2786 FLIS Packaging 2
| THK | UNIT CONT | PKG DATA SOURCE | INTER CONT | UCL | SPC MKG | LVL A | LVL B | LVL C |
|---|---|---|---|---|---|---|---|---|
| C | ZZ | P | 00 | E | Q |
7050-01-369-2786 FLIS Packaging 3
| UNIT PACK WEIGHT | UNIT PACK SIZE | UNIT PACK CUBE | CONT NSN | OPI | UNPKG ITEM DIM | UNPKG ITEM WEIGHT | SPI DATE | SPI NO | SPI REV | SUPPL INSTR |
|---|---|---|---|---|---|---|---|---|---|---|
| 0000.1 | 0000.024 | O |
