5962-01-059-6127 (5962010596127) NSN Information
| Photo | NSN | FSC | NIIN | Item Name | INC |
|---|---|---|---|---|---|
 | 5962-01-059-6127 | 5962 | 010596127 | Microcircuit, Digital | 31779 |
5962-01-059-6127 Features
| MRC | Parameter | Characteristics |
|---|---|---|
| ADAQ | Body Length | 0.890 inches nominal |
| ADAT | Body Width | 0.268 inches nominal |
| ADAU | Body Height | 0.180 inches nominal |
| AEHX | Maximum Power Dissipation Rating | 220.0 milliwatts |
| AFGA | Operating Temp Range | -55.0/+125.0 deg celsius |
| AFJQ | Storage Temp Range | -65.0/+150.0 deg celsius |
| CBBL | Features Provided | Hermetically sealed and programmed and low power and 3-STATE output |
| CQSJ | Inclosure Material | Ceramic |
| CQSZ | Inclosure Configuration | Dual-in-line |
| CQWX | Output Logic Form | Transistor-transistor logic |
| CQZP | Input Circuit Pattern | 12 input |
| TEST | Test Data Document | 97942-PDS22728 specification (includes engineering type bulletins, brochures, etc., that reflect specification type data in specification format; excludes commercial catalogs, industry directories, and similar trade publications, reflecting general type data on certain environmental and performance requirements and test conditions that are shown as "typical", "average", "nominal", etc.). and 81349-MIL-STD-883 level B standard (includes industry or association standards, individual manufactureer standards, etc.). |
5962-01-059-6127 Manufacturing Part Numbers (SKUs)
| MFG SKU | CAGE | STATUS | ISC | RNVC | RNCC | SADC | DAC | HCC | RNAAC |
|---|---|---|---|---|---|---|---|---|---|
| 637A129H01 | 97942 | A | 2 | 3 | 48 |
5962-01-059-6127 Manufacturer
| MFG SKU | CAGE | Manufacturer | Type | Status | Role |
|---|---|---|---|---|---|
| 637A129H01 | 97942 | Northrop Grumman Systems Corporation | A | A |
5962-01-059-6127 FLIS Identification
| PMIC | ADPE CODE | CRITL CODE | DEMIL CODE | DEMIL INTG | NIIN ASGMT | ESD | HMIC | ENAC | SCHEDULE_B | INC |
|---|---|---|---|---|---|---|---|---|---|---|
| U | N | Q | 3 | 13-APR-1978 | B | N | 8542900000 | 31779 |
5962-01-059-6127 FLIS Management
| MOE | REC REP CODE | MGMT CTL | USC | PHRASE CODE | PHRASE STATEMENT |
|---|---|---|---|---|---|
| GE | ------- | I |
5962-01-059-6127 Demilitarization Codes & Management
| DML | PMIC | HMIC | ADPEC | Criticality | ESDC |
|---|---|---|---|---|---|
| Q | N | N | B |
5962-01-059-6127 Miscellaneous Management
| MOE (S_A) | SOS | AAC | QUP | UI | SLC | CIIC | RC | MCC | SVC |
|---|---|---|---|---|---|---|---|---|---|
| GE | G69 | G | 1 | EA | 0 | U | ------- | I |
5962-01-059-6127 Non-consumable Item Support
| MOE RULE | NIMSC | DSOR |
|---|---|---|
| B481 |
5962-01-059-6127 Freight
| NMFC | NMFC SUB | UFC | HMC | LTL | LCL | WCC | TCC | SHC | ADC | ACC | ASH | NMF DESC |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 061700 | Z | 34580 | W | 72D | 3 | 9 | A | HZ |
