5945-01-294-4627 (5945012944627) NSN Information
| Photo | NSN | FSC | NIIN | Item Name | INC |
|---|---|---|---|---|---|
 | 5945-01-294-4627 | 5945 | 012944627 | Relay, Reed | 30544 |
5945-01-294-4627 Features
| MRC | Parameter | Characteristics |
|---|---|---|
| ABHP | Overall Length | 1.125 inches nominal |
| ABKW | Overall Height | 0.344 inches nominal |
| ABMK | Overall Width | 0.844 inches nominal |
| ADZC | Environmental Protection | Hermetic |
| AGAV | End Item Identification | Back-up emergency communications (buec) |
| AXHR | Mounting Facility Type and Quantity | 1 printed circuit terminal single mounting facility |
| TTQY | Terminal Type and Quantity | 4 printed circuit all functions |
5945-01-294-4627 Manufacturing Part Numbers (SKUs)
| MFG SKU | CAGE | STATUS | ISC | RNVC | RNCC | SADC | DAC | HCC | RNAAC |
|---|---|---|---|---|---|---|---|---|---|
| 1246A2RO | 1HY41 | A | 2 | 3 | 48 |
5945-01-294-4627 Manufacturer
| MFG SKU | CAGE | Manufacturer | Type | Status | Role |
|---|---|---|---|---|---|
| 1246A2RO | 1HY41 | American Relays Inc. | A | A |
5945-01-294-4627 FLIS Identification
| PMIC | ADPE CODE | CRITL CODE | DEMIL CODE | DEMIL INTG | NIIN ASGMT | ESD | HMIC | ENAC | SCHEDULE_B | INC |
|---|---|---|---|---|---|---|---|---|---|---|
| U | N | A | 7 | 16-FEB-1989 | N | 8536410020 | 30544 |
5945-01-294-4627 FLIS Management
| MOE | REC REP CODE | MGMT CTL | USC | PHRASE CODE | PHRASE STATEMENT |
|---|---|---|---|---|---|
| GE | ------- | I |
5945-01-294-4627 Demilitarization Codes & Management
| DML | PMIC | HMIC | ADPEC | Criticality | ESDC |
|---|---|---|---|---|---|
| A | N | N |
5945-01-294-4627 Miscellaneous Management
| MOE (S_A) | SOS | AAC | QUP | UI | SLC | CIIC | RC | MCC | SVC |
|---|---|---|---|---|---|---|---|---|---|
| GE | G69 | G | 1 | EA | 0 | U | ------- | I |
5945-01-294-4627 Non-consumable Item Support
| MOE RULE | NIMSC | DSOR |
|---|---|---|
| B481 |
5945-01-294-4627 Freight
| NMFC | NMFC SUB | UFC | HMC | LTL | LCL | WCC | TCC | SHC | ADC | ACC | ASH | NMF DESC |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
