5905-00-012-1167 (5905000121167) NSN Information
| Photo | NSN | FSC | NIIN | Item Name | INC |
|---|---|---|---|---|---|
 | 5905-00-012-1167 | 5905 | 000121167 | Resistor, Fixed, Film | 05311 |
5905-00-012-1167 Features
| MRC | Parameter | Characteristics |
|---|---|---|
| AAPE | Temp Coefficient of Resistance in PPM per DEG Celsius | -100.0 to 100.0 |
| AAPP | Electrical Resistance | 2.610 kilohms |
| AAPQ | Resistance Tolerance in Percent | -1.000 to 1.000 |
| AAQF | Unable to Decode | Unable to decode |
| AAQG | Ambient Temp in DEG Celsius at Zero Percent Rated Power | 165.0 |
| AAQH | Temp Range of Temp Coefficient in DEG Celsius | -55.0 to 165.0 |
| AAQZ | Inclosure Method | Encapsulated |
| AARB | Terminal Type | Wire lead |
| AARG | Reliability Indicator | Not established |
| ABJT | Terminal Length | 1.375 inches minimum and 1.625 inches maximum |
| ABPM | Body Diameter | 0.094 inches minimum and 0.165 inches maximum |
| ADAQ | Body Length | 0.283 inches minimum and 0.437 inches maximum |
| AEFB | Power Dissipation Rating in Watts | 0.250 free air |
| AEHY | Ambient Temp at Full Rated Power | 70.0 deg celsius |
| PKWT | Unpackaged Unit Weight | 0.5 grams |
| STYL | Style Designator | Axial terminal each end |
| TEST | Test Data Document | 95750-100000 drawing (this is the basic governing drawing, such as a contractor drawing, original equipment manufacturer drawing, etc.; excludes any specification, standard or other document that may be referenced in a basic governing drawing) |
5905-00-012-1167 Manufacturing Part Numbers (SKUs)
| MFG SKU | CAGE | STATUS | ISC | RNVC | RNCC | SADC | DAC | HCC | RNAAC |
|---|---|---|---|---|---|---|---|---|---|
| 100000-1237 | 95750 | C | 9 | 3 | TX | ||||
| MEAT0-2611F | 75042 | F | 9 | 5 | TX |
5905-00-012-1167 Manufacturer
| MFG SKU | CAGE | Manufacturer | Type | Status | Role |
|---|---|---|---|---|---|
| 100000-1237 | 95750 | Aeronautical Instrument & Radio Co. | A | C | |
| MEAT0-2611F | 75042 | TRW Inc. | A | F |
5905-00-012-1167 FLIS Identification
| PMIC | ADPE CODE | CRITL CODE | DEMIL CODE | DEMIL INTG | NIIN ASGMT | ESD | HMIC | ENAC | SCHEDULE_B | INC |
|---|---|---|---|---|---|---|---|---|---|---|
| A | X | A | 1 | 22-APR-1967 | A | N | 8533100042 | 05311 |
5905-00-012-1167 Demilitarization Codes & Management
| DML | PMIC | HMIC | ADPEC | Criticality | ESDC |
|---|---|---|---|---|---|
| A | N | X | A |
5905-00-012-1167 Non-consumable Item Support
| MOE RULE | NIMSC | DSOR |
|---|---|---|
| ZU01 |
5905-00-012-1167 Freight
| NMFC | NMFC SUB | UFC | HMC | LTL | LCL | WCC | TCC | SHC | ADC | ACC | ASH | NMF DESC |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 062960 | X | 35140 | P | 658 | Z | 9 | A | HZ |
5905-00-012-1167 FLIS Packaging 1
| PICA SICA | TOS | ICQ | MOP | CLNG DRYING | PRES MAT | WRAP MAT | PKG CAT | PKG DESIGN ACTY | CUSH DUN |
|---|---|---|---|---|---|---|---|---|---|
| P | AAA | 41 | 1 | 00 | 00 | 69F0 | 00 |
5905-00-012-1167 FLIS Packaging 2
| THK | UNIT CONT | PKG DATA SOURCE | INTER CONT | UCL | SPC MKG | LVL A | LVL B | LVL C |
|---|---|---|---|---|---|---|---|---|
| 0 | XX | P | 00 | Q | Q |
5905-00-012-1167 FLIS Packaging 3
| UNIT PACK WEIGHT | UNIT PACK SIZE | UNIT PACK CUBE | CONT NSN | OPI | UNPKG ITEM DIM | UNPKG ITEM WEIGHT | SPI DATE | SPI NO | SPI REV | SUPPL INSTR |
|---|---|---|---|---|---|---|---|---|---|---|
| 0000.0 | 0000.000 | O |
